Platinum case
Diameter: 40 mm
Overall height: 9.5 mm
Dial: grained Silver with hours display in blackened engraved Silver, fixed by a Steel polished circle
Hands: white coloured Steel Abraham-Louis Breguet hands, seconds hand in rhodium plated Steel

Calibre 1412

Technical Specifications

Movement :

Calibre exclusive F.P. Journe 1412
Manuel winding
Movement in 18K rose gold

Dimensions :

Overall diameter : 32.60 mm
Casing-up diameter : 32.00 mm
Overall height : 5.90 mm
Height of winding system : 2.50 mm
Diameter of stem thread : S1.20 mm

Characteristics :

Pallet escapement with 15 tooth escape wheel in 0°9
Four inertia weights
Flat Anachron micro flamed spring
Free sprung
Pinned GE stud
Two mainspring barrels in parallel

Frequency :

21'600 Alt/h, (3Hz)

Inertia :

11.00 mg*cm2

Angle of lift :

52°

Amplitude :

0h dial up: 320°
24h dial up: 260°

Display :

Off centre hours and minutes at 12:00
Small second at 6h00

Autonomy :

56 ± 2hours

Decoration :

Platinum or 18K 6N gold
Polished screw heads, chamfered slots
Pegs with polished rounded ends

Case :

Platinum PT 950
Sapphire background
Diameter : 40 mm
Height : 9.5 mm

Number of Parts :

Rubis : 19
Movement without dial: 178
Cased- up on leather strap : 223

Movement :

Calibre exclusive F.P. Journe 1412
Manuel winding
Movement in 18K rose gold

Dimensions :

Overall diameter : 32.60 mm
Casing-up diameter : 32.00 mm
Overall height : 5.90 mm
Height of winding system : 2.50 mm
Diameter of stem thread : S1.20 mm

Characteristics :

Pallet escapement with 15 tooth escape wheel in 0°9
Four inertia weights
Flat Anachron micro flamed spring
Free sprung
Pinned GE stud
Two mainspring barrels in parallel

Frequency :

21'600 Alt/h, (3Hz)

Inertia :

11.00 mg*cm2

Angle of lift :

52°

Amplitude :

0h dial up: 320°
24h dial up: 260°

Display :

Off centre hours and minutes at 12:00
Small second at 6h00

Autonomy :

56 ± 2hours

Decoration :

Platinum or 18K 6N gold
Polished screw heads, chamfered slots
Pegs with polished rounded ends

Case :

Platinum PT 950
Sapphire background
Diameter : 40 mm
Height : 9.5 mm

Number of Parts :

Rubis : 19
Movement without dial: 178
Cased- up on leather strap : 223

At the heart of the movement

Technical description

The Anniversary Tourbillon in Platinum presents an identical movement to the original Tourbillon of 1983, but manufactured in 18K rose Gold and visible through the sapphire back of the case. The dial in grained silver with blackened hour display, even rarer than the dial of the «Black Label» edition reserved to the Boutique, is maintained by a screwed steel polished circle. The hours are indicated by Abraham-Louis Breguet hands.

Technical description

Finishing

Calibre 1412

Technical Specifications

Movement :

Calibre exclusive F.P. Journe 1412
Manuel winding
Movement in 18K rose gold

Dimensions :

Overall diameter : 32.60 mm
Casing-up diameter : 32.00 mm
Overall height : 5.90 mm
Height of winding system : 2.50 mm
Diameter of stem thread : S1.20 mm

Characteristics :

Pallet escapement with 15 tooth escape wheel in 0°9
Four inertia weights
Flat Anachron micro flamed spring
Free sprung
Pinned GE stud
Two mainspring barrels in parallel

Frequency :

21'600 Alt/h, (3Hz)

Inertia :

11.00 mg*cm2

Angle of lift :

52°

Amplitude :

0h dial up: 320°
24h dial up: 260°

Display :

Off centre hours and minutes at 12:00
Small second at 6h00

Autonomy :

56 ± 2hours

Decoration :

Platinum or 18K 6N gold
Polished screw heads, chamfered slots
Pegs with polished rounded ends

Case :

Platinum PT 950
Sapphire background
Diameter : 40 mm
Height : 9.5 mm

Number of Parts :

Rubis : 19
Movement without dial: 178
Cased- up on leather strap : 223

Movement :

Calibre exclusive F.P. Journe 1412
Manuel winding
Movement in 18K rose gold

Dimensions :

Overall diameter : 32.60 mm
Casing-up diameter : 32.00 mm
Overall height : 5.90 mm
Height of winding system : 2.50 mm
Diameter of stem thread : S1.20 mm

Characteristics :

Pallet escapement with 15 tooth escape wheel in 0°9
Four inertia weights
Flat Anachron micro flamed spring
Free sprung
Pinned GE stud
Two mainspring barrels in parallel

Frequency :

21'600 Alt/h, (3Hz)

Inertia :

11.00 mg*cm2

Angle of lift :

52°

Amplitude :

0h dial up: 320°
24h dial up: 260°

Display :

Off centre hours and minutes at 12:00
Small second at 6h00

Autonomy :

56 ± 2hours

Decoration :

Platinum or 18K 6N gold
Polished screw heads, chamfered slots
Pegs with polished rounded ends

Case :

Platinum PT 950
Sapphire background
Diameter : 40 mm
Height : 9.5 mm

Number of Parts :

Rubis : 19
Movement without dial: 178
Cased- up on leather strap : 223

At the heart of the movement

Technical description

Find aboutique
Catalogue

10 Years Anniversary Tourbillon Calibre 1412 https://www.fpjourne.com/en/collection/limited-series/10-years-anniversary-tourbillon FP Journe https://www.fpjourne.com/en FP Journe

Other views

About

This model was produced in 2013
Limited Series numbered 1 to 10

The «10 Years Anniversary Tourbillon», a very exclusive Series, limited to only 10 timepieces. It combines the 10th Anniversary of the first F.P.Journe Boutique in Tokyo, jointly with the inauguration of the 10th Boutique in Beirut. Such a conjunction of numbers could indeed not go unnoticed.

A solution, for the least unusual, was found by François-Paul Journe for the attribution of these 10 exclusive timepieces: «Our ten Boutiques have each proposed us candidates among our faithful collectors. Their name will be randomly selected by draw during our annual fair in January 2014.»

The Anniversary Tourbillon in Platinum presents an identical movement to the original Tourbillon of 1983, but manufactured in 18K rose Gold and visible through the sapphire back of the case. The dial in grained silver with blackened hour display, even rarer than the dial of the «Black Label» edition reserved to the Boutique, is maintained by a screwed steel polished circle. The hours are indicated by Abraham-Louis Breguet hands.
